Features

CNC Plasma machine

Sol Welding Plasma Cut 130 A
CUT 120 A

In both plasma devices, the maximum amperage I can use is 60 A.

This is because the electrodes that can be supplied on the market in both cases have a maximum load-bearing capacity of 60 A.

Nozzles and electrodes

Nozzles

D 1.0- 60 A
D 1.4 - 90 A
D 1.5 - 90 A
D 1.6 - 120 A

Electrodes

Standard 60A

Coordinate table

Plasma machine is system with 3 gyded coordinates:

In plane: X and Y

Torch distance from the sheet: Z

Back to menu

Plazmakarakteristiki

plasmamenu

Toolpath controler

Mach 3

This toolpath controller is universal type. With it plasma machine system is controlled by three axes with the help of a CNC program with .tap extension.

Zeroing is with a reference zero. (we define ourselves where is zero position from where the program is implemented until the next definition of new zero position)

Code generator

Sheetcam

With this code generator, the drawing, or the scheme that we have formed and want to be cropped, translates into a CNC code with movement instructions and machine-specific operations. The drawing is with the extension .dxf. But not every dxf file is suitable for translation. The drawing should be generated with some CAD software that is intended for industrial application. From experience, the most suitable is the R12 / LT2 DXF format. If any graphic software is used, the translator will treat them as regions, so it will not recognize and translate them.

In the same generator, you also define cutting parameters for various thicknesses and materials, so you just call such ready-made definitions when generating the code.
